Function characteristics
● Accurate data: laser detection, reliable
● Fast response: Data update frequency is 1 Hz
● Easy integration: Serial port output (or 10 port output can be customized), comes with a fan
● High resolution: The minimum diameter of the resolution of the particles reaches 0.3 μm
● Standard authentication: CE/FCC/RoHS certification
Application scenarios
Nova SDS011 dust particle sensor is suitable for indoor monitoring and dust monitoring, and can be installed in PM2.5 detectors, purifiers, and micro air stations.
Technical parameter
NO. | Project | Parameter | Notes |
1 | Measuring output | PM2.5、PM10 |
|
2 | Range | PM2.5：0.0~1000.0μg/m3
PM10：0.0~2000.0μg/m3 |
|
3 | Rated voltage | 5V |
|
4 | Rated current | 90mA±10mA |
|
5 | Sleep current | ＜4mA | Laser and fan stop working |
6 | Temp. Range | Storage environment: -20~60℃ Work environment: -10~50℃ |
|
7 | Humidity range | Storage environment: Maximum 90%RH Work environment: Maximum 70%RH |
|
8 | Esponse time | 1S |
|
9 | Working AP | 86KPa~110KPa |
|
10 | Minimum resolution particle size | 0.3μm |
|
11 | Counting efficiency | 70%@0.3µm 98%@0.5µm |
|
12 | Relative error | ±15% & ±10µg/m3 MAX | @25℃，50%RH |
13 | Product size | 71*70*23mm |
|
