SDL511-031 Portable Dust Detector

SDL511-031 Portable Dust Detector

SDL511-031 portable dust detector is a high range portable dust concentration detector based on laser scattering principle, which can accurately measure mass concentrations including PM2.5, PM10, and TSP.

SDL511-031 portable dust detector has a large screen display and three button operation, which is simple and efficient to operate. It can achieve rapid detection in various high concentration dust scenarios. The built-in high-performance lithium battery can provide continuous operation of the dust detector for more than 4 hours, and it also has 512M storage, with a theoretical storage capacity of no less than 7000000 pieces of data. Monitoring data can be viewed in real-time on the screen and exported to a computer through the Type-C port for viewing and analyzing all data.

product introduction
download

Function characteristics

● Accurate data: Laser scattering principle, industrial grade laser source

● Quality concentration range: Standard range TSP: 0~100mg/m3

● Multi channel: capable of monitoring PM2.5 PM10、TSP

● High reliability: Industrial grade laser light source, maintenance free

● Stable flow rate: Factory default flow rate is 1.35~1.5L/min

● Fast response: second level data updates


Application scenarios

NovaSensor SDL511-031 portable dust concentration detector is suitable for high concentration dust monitoring scenarios such as flour mills, cement plants, power plants, construction sites, workshops, etc.


Technical parameter

NO.

Project

Parameter

Notes

1

Measuring output

PM2.5、PM10、TSP

Mass concentration

2

Range

0~100mg/m3


3

Power supply

DC16.8V/1A


4

Power

4.1W


5

Screen

4.3寸


6

Temp. Range

-20~60℃


7

Humidity range

0~99%RH


8

Working AP

86KPa~110KPA


9

Esponse time

1S


10

Battery flow

14.8V/1.5AH


11

Interface

USB2.0


12

Storage

Can store no less than 7 million pieces of data

Export files through USB Type-C port

13

Relative error

±20% & ±100μg/m3 Max

@25℃，50%RH

14

Size

203*104*63mm

Excluding sampling head

15EnduranceTheoretical battery life≥4h@25℃，50%RH
